Pre-engineered building (PEB) sheds leak mostly for predictable, fixable reasons — not bad luck. In a Makphalt survey of over 100 PEB shed owners and contractors, 56% of leaks traced to roof-sheet damage, 17% to installation issues, 12% to sealant failure, 8% to drainage problems and 7% to condensation. The permanent fix is to identify the real cause first, repair the sheets and joints, and then apply a liquid-applied waterproofing coating over the metal roof, its laps and its fasteners — simply patching the visible spot almost always fails again.
Why does a PEB shed leak?
Based on Makphalt’s survey of 100+ PEB shed owners and contractors, the causes break down as follows:
- Roof-sheet damage — 56%. Over time even tough metal roofing degrades, especially in industrial zones where acid rain accelerates it. Damaged or corroded sheets are the single biggest source of leaks.
- Installation issues — 17%. Poorly installed sheets and structure leave gaps that let water in. Cutting corners at installation is paid for later.
- Sealant failure — 12%. Sealants protect overlaps and connections; once they harden or crack, water gets straight through.
- Drainage problems — 8%. If water doesn’t drain, it pools and eventually finds a way in.
- Condensation — 7%. Temperature swings cause moisture on the underside of the roof — less common, but a real contributor.
Location matters: deterioration is faster in industrial areas because of higher acid-rain exposure, and slower in rural areas.
What is a liquid-applied waterproofing coating for metal roofs?
A liquid-applied waterproofing coating is a seamless, flexible membrane rolled or sprayed over the entire metal roof — sheets, overlaps and fastener heads — that cures into one continuous waterproof skin. Unlike spot-sealing, it bridges the hundreds of small gaps at laps and screws where PEB roofs actually leak, and it adds a corrosion-resistant barrier over the metal.
How to stop a PEB shed from leaking: step by step
- Find the real source. Deliberately test the roof with a jet-stream or water hose to locate where water actually enters — don’t guess from the stain below.
- Repair or replace damaged sheets. Address corroded or deformed sheets before any coating; coating over failing metal only buys a little time.
- Treat laps, fasteners and flashings. Seal overlaps, screw heads and junctions with a suitable sealant and reinforcing tape.
- Apply the liquid waterproofing coating. Over a clean, primed surface, apply the coating in the specified coats with reinforcement at critical joints.
- Fix drainage and ventilation. Ensure water drains freely, and improve ventilation to control the condensation that causes 7% of leaks.
- Schedule maintenance. Periodic inspections catch sheet and sealant damage before it becomes a leak — a routine jet-wash and check extends roof life.
Safety note: If water is reaching electrical fittings or wiring, switch off power and call an electrician before inspecting.
Makphalt’s solution for PEB and metal-roof waterproofing
Makphalt (M.K. Petro Products India Pvt. Ltd., manufacturing construction chemicals since 1985) makes liquid waterproofing coatings built for Indian metal-roof and PEB conditions — Mak Elastothane EMB — a weather- and UV-resistant elastomeric coating that seals sheets, laps and fasteners in one continuous membrane. Makphalt’s technical team can assess your shed and recommend the right system and number of coats. Contact Makphalt.
Frequently asked questions
Why does my PEB shed leak at the screws and fasteners? Fastener points and sheet overlaps are the most common leak paths because their sealants harden and crack over time. A liquid coating that seals over the fasteners and laps fixes this where spot-sealing fails.
Can you waterproof a metal roof without replacing the sheets? Yes — if the sheets are sound, a liquid-applied coating over a prepared, sealed surface waterproofs the roof without replacement. Badly corroded sheets must be repaired or replaced first.
What is the best coating for a leaking PEB or metal roof? A UV- and weather-resistant elastomeric liquid membrane that bonds to metal and bridges movement at laps and fasteners.
How often should a PEB roof be inspected? Inspect at least before and after each monsoon, checking sheets, overlaps and sealants so small damage is fixed before it leaks.
Does condensation cause PEB shed leaks? It can — temperature swings form moisture under the roof, which looks like a leak. Better ventilation and insulation reduce it; Makphalt’s survey attributed 7% of PEB leaks to condensation.
